Fundus Camera Types
Hongdee’s portable retinal camera has three models: FC-100, FC-200, and FC-161, which are used to evaluate both human eyes and animal eyes. In addition, we offer an OCT fundus camera model FC-3100.
Basic Specifications of each model:
- FC-100: 5MP camera; 3.5″ touch screen; manual focus; take pictures.
- FC-200: 12MP camera; 4.7″ touch screen; auto focus/auto image capture; take pictures and videos.
- FC-161: 12MP camera; 4.3″ touch screen; manual/auto focus; take pictures.
- FC-3100: 24MP camera; automatic focus and capture; 3.3mm minimum pupil size.
Ophthalmologists may choose from four models of fundus cameras to meet the needs of their practice and patients. If you can’t decide which model suits your business, click Send Inquiry Now below. Our professional team will get back to you shortly.
Retinal Camera Types
Hongdee manufactures three models of portable retinal cameras: FC-100, FC-161, and FC-200; plus an OCT fundus camera model: FC-3100. You can send an inquiry on our website to get more retinal camera details. And, if you’re not sure which type is the most appropriate type for you, feel free to contact us.
Their differences are as follows:
| Model | FC-100 | FC-200 | FC-161 |
| Camera | 5MP | 12MP | 12MP |
| Screen Size | 3.5″ | 4.7″ touchscreen | 4.3″ touchscreen |
| Field of view | 42 degrees | 50 degrees | 45 degrees |
| Focus | Manual focus | Autofocus/auto image capture | Manual/Automatic |
| Working time | 3 hours | 8 hours | 6 hours |
| WIFI/blue tooth | WIFI/USB 2.0 | WIFI/Blue tooth/USB 3.0 | WIFI/USB |
| Picture/Video | picture | both picture and video | picture |
| DICOM | N/A | Supported | Supported |
| Language setting | English | English, and Spanish | English and Chinese |
FC-100 Retinal Camera Overview
Features
- Real-time Wi-Fi transfer.
- Compact and portable, very easy to carry around for mobile examination.
- Non-mydriatic, the retinal image of the eye can be taken right away once it is in focus.
- 3.5” screen provides a clear display of the retinal image to make it easy for doctors to analyze.
- 3-hours of continuous battery time make it possible to do more patient exams.
Specifications:
| Field Of View | 42° |
| Minimum Pupil | 2.5mm |
| Refractive Compensation | -20d-+20d |
| Focus Mode | manual |
| Image Resolution | 1920×1080 |
| Screen | 3.5” |
| Power | ≤6va |
| Picture Format | jpeg/av |
| Light Source | white led/ir |
| Storage | 32gb micro sd card |
| Battery | 3.6v lithium battery |
| Interface | Micro USB |
| Unit Size | 19cmx10cmx21cm |
| N.W | 400g |
FC-200 Retinal Camera Oview
Features
- 12 MP built-in camera to guarantee incredible image clarity and sharpness.
- Field of view up to 50 degrees to ensure faster and easier diagnosis.
- Autofocus and image capture to take a picture with a single button for easy operation.
- 4.7” touch screen offers ease of use in exams.
- Wif-FI and Bluetooth allow for quick transfer of images and videos.
- 3500Mah rechargeable lithium battery provides more than 8 hours of continuous operation without interruption.
Specifications
| Camera | 12MP |
| FOV | 50 degree |
| Sensor resolution | 12 Megapixels |
| Optical resolution | >60lp/mm |
| Min. pupil | 2.5mm |
| Focus | Autofocus |
| Flash mode | White LED and IR LED |
| Screen | 4.7 inch TFT colored screen |
| Format | JPEG, MPEG-4/1, Dicom3.0, |
| Internal targets | 5 targets fixation |
| Image Transfer | USB3.0, WIFI, SD card, HDMI |
| Storage | 4G+64G |
| Power | Li-on rechargeable battery 3.7V/3500mAh |
| Charging power | 100-240VAC,50/60Hz |
| Working time | >8 hours |
| Charging time | <2 hours |
| Net weight | <500g |
| Size | 205*125*205mm |
FC-161 Retinal Camera Overview
Features
- High Resolution Camera
- Non-mydriatic
- 9 Fixation Targets
- Smart Touch Operation
- Real-time Uploading
Specifications
| Filed of View | 45 degrees |
| Camera Sensor Resolution | 12M Pixels |
| Fixation Targets | 9×LED,Internal |
| Minimum Pupil Size | 3mm |
| Illumination | White LED |
| Focusing | Manual/Automatic |
| Focus Range | -20D-+20D |
| Display | 4.3” Touch Screen |
| Picture/Video | Only picture |
| Image Format | JPEG |
| Type of Image | Color |
| Memory | Micro SD card. Maximum 32G |
| Data Connectivity | WIFI/USB |
| Power Supply | Rechargeable battery 3.7V/3400mAh x 2 |
| Working Time | 6 hours |
| Charging Station | 100-240V，0.5A，50/60Hz |
| Power Supply | 5V DC,2A |
| Dimensions | 28cm×13cm×15cm |
| Weight | 800g |
| Languages | Chinese and English |
FC-3100 OCT Fundus Camera Overview
Features
- 180-degree rotation with a 10.1″ touch panel monitor.
- 24MP camera to exhibit fully crystal clear and true color fundus image.
- Automatic focus and capture of high-resolution true color fundus photos with a fully motorized chin rest to adjust the height of the patient’s head automatically.
- Small Pupil Mode enables the operator to acquire retinal images with pupils as small as 3.3mm.
- Soft lighting technology reduces the constriction of the pupil caused by over-illumination.
- Up to 9,216 internal fixation targets (Disc, Center, and Macula) as well as a single external fixation target for peripheral photography.
- DICOM 3.0, USB/LAN /FTP.
Specifications
| Operation | Automatic(one key taking picture)/Manual |
| Acquisition modes | Fundus/anterior/red-free filter/FFA(optional)/FAF（optional） |
| Filed of view | 45-50degee |
| Mosaic degree | 135degree |
| Minimum pupil size | 3.3mm |
| Resolution | Above18 megapixels (24 megapixels optional ) |
| Fixation | Countless fixation, any position is available during range + 1 outside fixation |
| Technology of focus | Dual camera technology |
| Exposure light | New technology, softer, one patient same eye can take pictures consecutive with almost the same performance |
How Do Four Types Of Fundus Camera To Work?
Four types of fundus cameras are available from Hongdee with a variety of specifications and functions. How does a fundus camera work? Click on the image to view the product video.
Customer Story
Brian, an Ophthalmologist in Florida with expertise and skills in the Ophthalmic equipment field, managed two clinics. In May of 2020, he decided to expand his business. He ordered three fundus camera samples from Hongdee, as well as other brands in China. Within three weeks, Brian said, “I fell in love with the appearance and quality of Hongdee’s FC-100 retinal camera. It’s the best among them.
Then, Brian had a special request. Brian asked us to brand the FC-100 not only with his company’s logo on the packaging and on the camera body but also prominently displayed on the screen. This unique requirement posed a challenge. Joana, Hongdee’s sales manager, promptly collaborated with the technical team to explore possibilities. Although such customization usually required a minimum order of 100 units, Hongdee devised a flexible solution. Brian agreed to order the 100-unit quantity, while Hongdee agreed to supply the customized FC-100 cameras in batches throughout the year.
Also, Hongdee provided Brian’s business with comprehensive marketing materials like product photos, videos, catalog, and technical documents, as well as assisted him with website development. This level of unwavering support exemplifies Hongdee’s commitment to the highest level of customer service.
Our OEM business program is ready to support your business with tailored solutions. Let Hongdee be your Ophthalmic business partner.
Customer Testimoinals
Thousands of fundus camera manufacturers in the world. How to verify which company is real and trustworthy? Verifying customer voices is one of the most important factors. They are direct testimonials of Hongdee’s services and product quality.
Therefore, Join Hongdee and be a partner with Hongdee, we can help to make your business to go up another level. It’s free to send your inquiry on our website. Or, you can email us directly.
Package And Shipping
All portable retinal camera in Hongdee is packed in a handheld box first. Then the handheld box is packed with a standard export carton box, which is moisture-proof, water-proof, and shockproof.
A portable fundus camera is shipped by express or air freight. If you have your own freight forwarder, we will ship to the specific address. If you do not have your own forwarder, we will ship according to your needs. Also, we can provide free support for customs clearance.
Retinal Camera Applications
Fundus photographs of non mydriatic fundus camera are ocular documentation that records the appearance of a patient’s retina. Optometrists, Ophthalmologists, Orthoptists, and other medical specialists use fundus photography for monitoring the progression of certain eye conditions/diseases. Fundus photographs are also used to document abnormalities of disease processes affecting the eye, and/or to follow up on the progress of the eye condition/disease such as diabetes, age-related macular degeneration (AMD), glaucoma, multiple sclerosis, neoplasm of the choroid, cranial nerves, retinal or eyeball.
Fundus photography of non mydriatic fundus camera in animals is a useful tool utilized for veterinary research, veterinary Ophthalmology, as well as veterinary medical education. Numerous studies have used fundus camera in research methods for the study of ocular and systemic conditions in animals.
Besides non mydriatic fundus camera, other Hongdee Ophthalmic equipment is used in veterinary medicine, like our portable slit lamp and rebound tonometer.
Related Products
Services For You
- Product Warranty: 12-month warranty; Free parts replacement within the warranty period. Unconditional 30-days return. Notify us within 30-days after receipt if you’d like to return the fundus camera.
- Custom Clearance Assistance: we can offer some files to help you with customs clearance.
- OEM Set Up: we can customize the fundus camera functions according to your requirements.
- Marketing Materials: Photos, videos, website design, and FDA-certificate registration.
